Produced in stainless steel by Aunov Tech, the Stamped Motor Mount Bracket is formed and machined on the same floor. In the assembly, the stamped bracket mounts the assembly to the vehicle body and keeps alignment under torque. Forming and machining share equipment, staff and batch records, and a design change is re-sampled in one place without re-quoting the job elsewhere.
Product overview
What defines this metal bracket is, wall thickness control, flange geometry and the sealing surface, all held to the drawing and verified at first article.
Die building, pressing and machining for this metal bracket are all in house, so the route from print to sample stays short, with process data archived for repeat orders.
How it is manufactured
The process for this metal bracket runs in a fixed sequence: The strip is blanked, formed and pierced in a progressive die; strip utilisation is planned so the material cost stays predictable.
Repeat motor mount bracket orders are measured against the approved sample, so neither material nor finish drifts between lots. Any change to the motor mount bracket drawing is re-approved and re-verified before production continues.
Materials and finishing
Everything is drawn from a fixed stock list: carbon steel SPCC / DC01, 304 and 316 stainless, aluminium, brass and copper with carbon steel or stainless specified on the drawing for this metal bracket.
Coating and polishing are matched to the end use: zinc and nickel plating, chrome, anodising, powder coating and passivation. It is written into the drawing for this metal bracket, so it cannot drift between batches.
Ask for motor mount bracket material certificates and dimensional reports with your order.
Quality control
An ISO 9001 certified system governs production: material traceability starts with mill certificates, the first article is CMM-measured against the print, and later batches follow the sampling plan agreed at approval. On the stamped bracket itself, hole positions are checked on a fixture at first article, and formed flatness is gauged each run. Where the application asks for it, torque, leak or pressure testing is added to the plan, and the report is packed with the shipment.
Typical applications
The metal bracket is specified into industrial machinery and equipment assemblies for OEM and Tier-1 customers.
One part number for this metal bracket frequently serves several assemblies, so one tooling set serves every position, and cost per piece stays at the volume tier.
Specifications
| Item | Stamped Motor Mount Bracket |
|---|---|
| Brand | AUNOV |
| Designing | Quotation follows the print, not a catalogue – unusual walls, threads or tolerances are feasibility-checked first; the agreed version governs every later batch. |
| Tooling | Tooling is built and held under your part number, so tooling lead time stays under our control, and the charge is refundable against agreed volumes. |
| Samples | Pre-production samples come with a full inspection report, so the part is proven before it is made in volume, and production starts only after your written sign-off. |
| Materials | Carbon steel (SPCC / DC01), 304 / 316 stainless, aluminium, brass and copper – the grade is matched to the duty of this bracket. |
| Surface finish | Finish selected from the drawing: plating, coating, anodising or passivation; masking and laser marking available where needed. |
| Processing | Blanking and progressive forming on automated lines, then secondary tapping, bending and finishing. |
| Equipment | 5-250 T presses running progressive and compound dies, with CNC turning centres for secondary operations and CMM inspection. |
| Tolerance | +/-0.05 mm on formed features, +/-0.1 mm on overall length; critical dimensions carry CMM data with the shipment. |
| Delivery terms | CIF or DDP, with FOB available, payment by T/T or L/C, quoted in USD or EUR; each volume tier carries its own quoted price. |
