The Galvanized Stamped Clip Bracket is produced by Aunov Tech from stainless steel, formed and finished under one roof. In operation, the stamped bracket mounts the assembly to the vehicle body and keeps alignment under torque. Forming, machining and inspection share one floor, which keeps tolerances consistent from sample to volume on one production route.
Product overview
What defines this metal bracket is, wall thinning, concentricity and the finished mating faces, all held to the drawing and verified at first article.
Toolroom, presses and machining centres used on this metal bracket operate on the same site, so revisions do not wait on outside suppliers, and every step is logged against the part number.
Production route
Production of this metal bracket is locked to one route: The strip is blanked, formed and pierced in a progressive die; secondary tapping, bending and deburring follow on the same site.
Batch records for the clip bracket are filed against the part number, so process settings are reused instead of re-invented. That record is what every clip bracket reorder is built on, so nothing changes silently between shipments.
Materials and finishing
Everything is drawn from a fixed stock list: SPCC / DC01 carbon steel, 304 / 316 stainless, aluminium, brass, copper and bronze and the grade agreed for this metal bracket is carbon steel or stainless.
Finish selection follows the working environment: polishing, zinc / nickel / chrome plating, anodising or powder coating. The finish on this metal bracket is locked to the drawing revision, so later orders match.
Each clip bracket shipment is verified against the master sample before it leaves the shop. That record is what every clip bracket reorder is built on, so nothing changes silently between shipments.
Quality control
The plant is ISO 9001 certified: mill certificates cover every delivery of stock, first articles are measured on a CMM, and production batches are inspected on a sampling plan. For the stamped bracket, hole positions are checked on a fixture at first article, and formed flatness is gauged each run. Functional testing – torque, leak or pressure – can be written into the plan, and the batch file carries the results.
Applications
The metal bracket is specified into industrial and appliance assemblies for customers who own the drawing and the tooling.
The same metal bracket is used across several platforms, so one approved version covers the whole range, and the die does not have to change.
Specifications
| Item | Galvanized Stamped Clip Bracket |
|---|---|
| Brand | AUNOV |
| Designing | Your drawing sets the part – samples are reverse-measured into a controlled drawing; the same drawing is used for every repeat order. |
| Tooling | Dies, fixtures and gauges are made in our own toolroom, so tooling lead time stays under our control, and the die remains dedicated to your part. |
| Samples | Prototype and pre-production samples are provided against the drawing, so any deviation is corrected at sample stage, and mass production is gated on that approval. |
| Materials | Carbon steel (SPCC / DC01), 304 / 316 stainless, aluminium, brass and copper – the grade is matched to the duty of this bracket. |
| Surface finish | Plating, coating or polishing to suit the drawing; finish thickness and adhesion checked on the first article. |
| Processing | Die stamping with in-press forming and piercing; every stage is logged against your part number. |
| Equipment | Press shop with 5-250 T mechanical presses and dedicated dies, with in-house toolmaking to keep dies and fixtures maintained. |
| Tolerance | +/-0.03 mm on pierced holes, +/-0.1 mm on formed sections; dimensional reports accompany the first article. |
| Delivery terms | FOB, with DDP offered for EU and US addresses, payment by T/T or L/C, quoted in USD or EUR; repeat orders reuse the approved first article. |
