The Stamped Round-Base Mounting Bracket is produced by Aunov Tech from stainless steel, formed and finished under one roof. In operation, the stamped bracket locates and carries the mating component under load and vibration. Die work, machining and CMM inspection are all in-house, so the approved sample defines every later batch under one roof.
Product overview
For this metal bracket, the drawing centres on, wall thickness control, flange geometry and the sealing surface, recorded on the inspection report for every batch.
The press shop and machine shop that make this metal bracket share one floor, so feasibility questions are answered on the shop floor, with the tooling history retained in house.
Production route
Every metal bracket follows the same routed path: Blanking and forming run in progressive tooling; strip utilisation is planned so the material cost stays predictable.
Route cards follow each round-base mounting bracket batch through the shop, so the next run starts from the data that already worked. Process settings for the round-base mounting bracket are archived, so later runs can be compared with the one you approved.
Materials and finishing
Our stock list runs to SPCC / DC01 carbon steel, 304 / 316 stainless, aluminium, brass, copper and bronze and this metal bracket runs in carbon steel or stainless.
The finish is chosen for the duty it will see: electrophoresis, powder coating, anodising and zinc / nickel plating. The agreed finish for this metal bracket travels with the part number on every reorder.
Each shipment is verified against the master sample, with mill certificates filed per heat.
Quality control
The factory operates with ISO 9001 certification: mill certificates cover every delivery of stock, first-article geometry is confirmed on the CMM, and routine sampling keeps batches aligned with the first article. For the stamped bracket, hole positions are checked on a fixture at first article, and formed flatness is gauged each run. Torque, leak and pressure tests are available where the assembly needs them, and the inspection report ships with each batch.
Applications
You will find this metal bracket inside industrial and appliance assemblies in volume programmes as well as aftermarket supply.
The same metal bracket is often run in more than one assembly, so the tightest tolerance in the family sets the spec, and the same first article applies throughout.
Specifications
| Item | Stamped Round-Base Mounting Bracket |
|---|---|
| Brand | AUNOV |
| Designing | Send drawings, or send a sample to be measured – a manufacturability review comes back with the quotation; the approved drawing is kept as the controlled master. |
| Tooling | Dies, fixtures and gauges are made in our own toolroom, so the die charge appears as its own quotation line, and the die remains dedicated to your part. |
| Samples | Sample lead time is quoted with the order, and the approved sample governs the run. |
| Materials | Carbon steel, 304 / 316 stainless, aluminium and brass are all held in stock; the final grade is fixed with the drawing review. |
| Surface finish | Surface treatment matched to the duty: plating, coating or polishing; alternatives quoted with the quotation, samples approved in writing. |
| Processing | Coil-fed stamping, deburred and finished to the print; in-process checks sit between stages, not only at the end. |
| Equipment | Mechanical presses 5-250 T, in-press forming and piercing; first articles and batch samples are checked on the CMM. |
| Tolerance | +/-0.05 mm on bend positions, +/-0.1 mm on blank outline; GD&T per drawing, PPAP-style reports on request. |
| Delivery terms | FOB Ningbo or Shanghai, payment by T/T or L/C, quoted in USD or EUR; call-off schedules are supported. |
