This Multi-Hole Stamped Mounting Bracket is an Aunov Tech production part in stainless steel, quoted and built to customer print. On the product, the stamped bracket mounts the assembly to the vehicle body and keeps alignment under torque. Die work, machining and CMM inspection are all in-house, so the approved sample defines every later batch without handing the part to another vendor.
Product overview
What defines this metal bracket is, the forming route, the tolerance band and the sealing faces, re-checked whenever the drawing is revised.
Die work and machining for this metal bracket sit on the same floor, which keeps the sample loop inside our own schedule, with process data archived for repeat orders.
How it is manufactured
Every metal bracket follows the same routed path: Blanking and forming run in progressive tooling; deburring and finishing are completed before packing.
Production batches of the multi-hole mounting bracket are gauged back to the signed first article, not to a memory of it. That record is what every multi-hole mounting bracket reorder is built on, so nothing changes silently between shipments.
Materials and finishing
Our stock list runs to SPCC / DC01 carbon steel, 304 / 316 stainless, aluminium, brass, copper and bronze with carbon steel or stainless specified on the drawing for this metal bracket.
The finish is chosen for the duty it will see: plating, anodising, powder coating, electrophoresis and passivation. It is fixed on the drawing for this metal bracket, so repeat orders never reopen the question.
Route cards follow each multi-hole mounting bracket batch through the shop, so the next run starts from the data that already worked. That record is what every multi-hole mounting bracket reorder is built on, so nothing changes silently between shipments.
Quality control and inspection
Production runs under an ISO 9001 certified quality system: stock arrivals are checked against mill certificates, a full CMM report approves the first article, and routine sampling keeps batches aligned with the first article. For the stamped bracket, hole positions are checked on a fixture at first article, and formed flatness is gauged each run. Torque, leak and pressure tests are available where the assembly needs them, and results travel with the batch paperwork.
Where the part is used
The metal bracket is specified into industrial and appliance assemblies for customers who own the drawing and the tooling.
One drawing for this metal bracket is commonly applied to several programmes, so one approved version covers the whole range, and approvals carry across programmes.
Specifications
| Item | Multi-Hole Stamped Mounting Bracket |
|---|---|
| Brand | AUNOV |
| Designing | DFM feedback accompanies the quotation, so surprises are caught before the die is cut. |
| Tooling | Progressive and drawing dies are designed and built in house, so the die charge appears as its own quotation line, and the charge is refundable against agreed volumes. |
| Samples | Samples are issued for approval before the run, and production starts only after written sign-off. |
| Materials | Stock runs to carbon steel, 304 / 316 stainless, aluminium and brass; mill certificates and heat numbers accompany the first article. |
| Surface finish | Plating, coating or polishing to suit the drawing; finish thickness and adhesion checked on the first article. |
| Processing | Blanking and progressive forming on automated lines, then secondary tapping, bending and finishing. |
| Equipment | Press shop with 5-250 T mechanical presses and dedicated dies, backed by CNC turning centres and a climate-controlled inspection room. |
| Tolerance | +/-0.05 mm on bend positions, +/-0.1 mm on blank outline; finer bands confirmed from capability data before quoting. |
| Delivery terms | Delivery quoted per Incoterms 2020 – FOB, CIF or DDP – by sea or air, to your address. |
